Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support

  • Product Details
  • Company Profile

Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support

Advantages
Key Features
Self-developed and highly reliable pump
source to achieve ultra-long service life

Applications
·Metal processing station
·Construction and piping
·Auto body application
·Aerospace&transportation
·Maintenance and repair

Parameters
Pump Power
Input power
Wobble frequency and width
Size
Weight
2200W
220V single phase,24A
120HZ,5mm
500*530*260mm³
42kg
Welding material
Stainless steels
Galvanized sheet
Carbon steel
Aluminum
Brass
Copper
One-sided
fusion depth
5mm
5mm
5mm
4mm
3mm
2mm
Double-sided
dissolving depth
10mm
10mm
10mm
8mm
6mm
4mm
Laser welding·Washing
Power Stability
Plenty of power reserve at rated power output.
Powerful Performance
Effective fusion depth 5mm for stainless steel, 2mm for copper
Intelligent
Fully intelligent and simple operating system, simple to set up, easy to learn and operate.
Wobble Welding
Wobble width up to 5mm, supports wide seam welding.
Excellent welding seam
Sufficient pumping power and precise energy control contributing to stable laser beam
quality and narrowed heat-affected zone.
Operator Safety
Multi-level sensors and interlocking safety devices.
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
1.How long is the warranty period? Whole machine warranty period is 1 year, laser source 2 years. If there is any problem during the period, we will solve it as soon as possible. 2.How long is the cable? Different laser source have different option. For example, the normal cable length of raycus and max is about 9 meters. 3.How thick can 1500w-3000W be welded 1-8mm thick metal materials. 4.Is there a wire feeder? We have a wire feeder to choose from. If you are interested, you can contact us and provide your email address.We will send more detailed pictures to your email. 5.Can aluminum and galvanized steel be welded? Yes, it can. 6.Packaging All our machines are packed in wooden boxes. 7.Language interface Supports language customization, etc. You can also translate and insert to software.
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
Handheld Laser Welding Machine with 3mm Welding Depth Raycus MAX IPG Laser Source and Online Support
